供應聚源磨擦式中速分切機

    磨擦式中速分切機
·產品用途：
該機適用于BOPP、PET、CPP、CPE、PVC薄膜卷筒狀材料的高精度盤條切切和復卷。
·Product use
This machine is used to cutting and rewinding of drum-shaped plastic film such as BOPP,PET,CPP,CPE,and PVC with high precision.

·主要配置特點
1、本機采用左、腫氣漲軸交錯有面中心收卷進方式，適應多數條分切。
2、主機變頻調速；恒速主橡膠傳動，使分切速度恒定。
3、備有長度自動計米，可設定一定長度自動停機等功能。
4、配有平刀裝置及邊料風機吹出。
5、本機放卷采用磁粉制動器控制張力。
6、放卷原料采用自動上料裝置。
7、配備光電糾編，能自動跟蹤分切基材的邊進行精確的盤條分切。
·Main configuration characteristics
1.this machine adopt left/right pneumatic shaft interlace center rolling mode,suitable for multi-strip cutting.
2.Main machine adjusts speed with variable frequency,main rubber transmission with constant speed,which makes the cutting speed constantly.
3.With function of auto count meter for length,auto halt at certain length.
4.With anvil blade and blower for rim charge.
5.Unreeling adopts magnetic actuator with tension control.
6.Unreeling material adopts auto loading equipment.
7.With photoelectric correction system,which can cutting precisely by tracing the brim of raw material.
·技術參數機器運行速度：5-380M/MIN
放卷直徑：∮800MM
機型寬度：650-2500MM
分切寬度：20-2500MM
收卷直徑：∮500MM
糾偏方式：光電跟蹤/跟邊或跟蹤
張力控制：磁粉恒張力控制
總功率：2.2-8.5KW
·The main features
The speed of the machine:5-380m/min
Rewinding diameter:∮8010mm
Machine width:650-2500mm
Slitting width:20-2500mm
Rewinding diameter:∮500mm
Correction:photoelectric tracking/with edge or tracking
Tension control:the constant tension control of magnetic powder
Total power:2.2-8.5kw
